Stream a video

1
// This Go example uses the Lattice REST SDK (lattice-sdk-go) to publish a camera asset entity.
2
// Attaching a video to an asset requires the asset to already exist as a Lattice entity, so
3
// publish the camera on a heartbeat before starting an ingress stream.
4
package main
5
6
import (
7
	"context"
8
	"fmt"
9
	"net/http"
10
	"os"
11
	"time"
12
13
	Lattice "github.com/anduril/lattice-sdk-go/v5"
14
	"github.com/anduril/lattice-sdk-go/v5/client"
15
	"github.com/anduril/lattice-sdk-go/v5/option"
16
	"github.com/google/uuid"
17
)
18
19
const (
20
	cameraName          = "camera-01"
21
	integrationName     = "lattice_video_integration"
22
	dataType            = "camera_video_feed"
23
	publishInterval     = 5 * time.Second
24
	entityExpiryTtlSecs = 60
25
)
26
27
func main() {
28
	// Get environment variables
29
	latticeEndpoint := os.Getenv("LATTICE_ENDPOINT")
30
	clientSecret := os.Getenv("LATTICE_CLIENT_SECRET")
31
	clientId := os.Getenv("LATTICE_CLIENT_ID")
32
33
	// Remove sandboxesToken from the following statements if you are not developing on Sandboxes.
34
	sandboxesToken := os.Getenv("SANDBOXES_TOKEN")
35
36
	// Check required environment variables
37
	if latticeEndpoint == "" || clientId == "" || clientSecret == "" || sandboxesToken == "" {
38
		fmt.Println("Missing required environment variables")
39
		os.Exit(1)
40
	}
41
42
	// Initialize headers for sandbox authorization
43
	headers := http.Header{}
44
	headers.Add("Anduril-Sandbox-Authorization", fmt.Sprintf("Bearer %s", sandboxesToken))
45
46
	// Create the client
47
	LatticeClient := client.NewClient(
48
		option.WithClientCredentials(clientId, clientSecret),
49
		option.WithBaseURL(fmt.Sprintf("https://%s", latticeEndpoint)),
50
		option.WithHTTPHeader(headers),
51
	)
52
53
	// Stable entity ID derived from the camera's hardware identifier so the same
54
	// physical camera maps to the same Lattice entity across restarts.
55
	entityId := uuid.NewSHA1(uuid.NameSpaceURL, []byte(cameraName)).String()
56
57
	creationTime := time.Now().UTC()
58
59
	// Continuously publish the entity so it does not expire.
60
	for {
61
		latestTimestamp := time.Now().UTC()
62
		ctx := context.Background()
63
64
		entity := Lattice.Entity{
65
			EntityID:    &entityId,
66
			Description: Lattice.String("EO camera streaming live video"),
67
			Aliases: &Lattice.Aliases{
68
				Name: Lattice.String("Camera 01"),
69
				AlternateIDs: []*Lattice.AlternateID{
70
					{
71
						ID:   Lattice.String(cameraName),
72
						Type: Lattice.AlternateIDTypeAltIDTypeSerialNumber.Ptr(),
73
					},
74
				},
75
			},
76
			IsLive:      Lattice.Bool(true),
77
			CreatedTime: Lattice.Time(creationTime),
78
			// ExpiryTime is set in the future and paired with a shorter publish loop,
79
			// so the entity stays alive as long as the publisher runs.
80
			ExpiryTime: Lattice.Time(latestTimestamp.Add(entityExpiryTtlSecs * time.Second)),
81
			Ontology: &Lattice.Ontology{
82
				Template:     Lattice.OntologyTemplateTemplateAsset.Ptr(),
83
				PlatformType: Lattice.String("CAMERA"),
84
			},
85
			MilView: &Lattice.MilView{
86
				Disposition: Lattice.MilViewDispositionDispositionFriendly.Ptr(),
87
				Environment: Lattice.MilViewEnvironmentEnvironmentLand.Ptr(),
88
				Nationality: Lattice.MilViewNationalityNationalityUnitedStatesOfAmerica.Ptr(),
89
			},
90
			// Overall classification of the entity's data.
91
			DataClassification: &Lattice.Classification{
92
				Default: &Lattice.ClassificationInformation{
93
					Level: Lattice.ClassificationInformationLevelClassificationLevelsUnclassified.Ptr(),
94
				},
95
			},
96
			Location: &Lattice.Location{
97
				Position: &Lattice.Position{
98
					LatitudeDegrees:   Lattice.Float64(36.66633492530301),
99
					LongitudeDegrees:  Lattice.Float64(-116.9117674522639),
100
					AltitudeHaeMeters: Lattice.Float64(780.0),
101
				},
102
			},
103
			Provenance: &Lattice.Provenance{
104
				IntegrationName:  Lattice.String(integrationName),
105
				DataType:         Lattice.String(dataType),
106
				SourceUpdateTime: Lattice.Time(latestTimestamp),
107
			},
108
			Health: &Lattice.Health{
109
				ConnectionStatus: Lattice.HealthConnectionStatusConnectionStatusOnline.Ptr(),
110
				HealthStatus:     Lattice.HealthHealthStatusHealthStatusHealthy.Ptr(),
111
				ActiveAlerts:     []*Lattice.Alert{},
112
				UpdateTime:       Lattice.Time(latestTimestamp),
113
				// Per-subsystem health rolls up into the entity's overall
114
				// health_status; report at least the camera sensor itself.
115
				Components: []*Lattice.ComponentHealth{
116
					{
117
						ID:         Lattice.String("camera-01-eo"),
118
						Name:       Lattice.String("EO camera sensor"),
119
						Health:     Lattice.ComponentHealthHealthHealthStatusHealthy.Ptr(),
120
						UpdateTime: Lattice.Time(latestTimestamp),
121
					},
122
				},
123
			},
124
			// Declare the camera as a sensor so Lattice can render the sensor cone.
125
			Sensors: &Lattice.Sensors{
126
				Sensors: []*Lattice.Sensor{
127
					{
128
						SensorID:          Lattice.String("camera-01-eo"),
129
						SensorType:        Lattice.SensorSensorTypeSensorTypeCamera.Ptr(),
130
						OperationalState:  Lattice.SensorOperationalStateOperationalStateOperational.Ptr(),
131
						SensorDescription: Lattice.String("EO camera, H.264"),
132
						FieldsOfView: []*Lattice.FieldOfView{
133
							{
134
								CenterRayPose: &Lattice.EntityManagerPose{
135
									Orientation: &Lattice.Quaternion{
136
										X: Lattice.Float64(0.0),
137
										Y: Lattice.Float64(0.0),
138
										Z: Lattice.Float64(0.0),
139
										W: Lattice.Float64(1.0),
140
									},
141
								},
142
								HorizontalFov: Lattice.Float64(1.204), // ~69 deg (typical EO horizontal FoV)
143
								VerticalFov:   Lattice.Float64(0.954), // ~54.6 deg (typical EO vertical FoV)
144
								Range:         Lattice.Float64(150.0),
145
								Mode:          Lattice.FieldOfViewModeSensorModeSearch.Ptr(),
146
							},
147
						},
148
					},
149
				},
150
			},
151
			TaskCatalog: &Lattice.TaskCatalog{
152
				TaskDefinitions: []*Lattice.TaskDefinition{
153
					{TaskSpecificationURL: Lattice.String("type.googleapis.com/<org>.<package>.<version>.<task>")},
154
				},
155
			},
156
		}
157
158
		// Publish the entity
159
		_, err := LatticeClient.Entities.PublishEntity(ctx, &entity)
160
		if err != nil {
161
			fmt.Printf("Error publishing entity: %v\n", err)
162
		} else {
163
			fmt.Printf("Publishing asset with entity ID: %s\n", entityId)
164
		}
165
166
		time.Sleep(publishInterval)
167
	}
168
}

1
// This Go example uses the Lattice REST SDK (lattice-sdk-go) to start an RTSP ingress stream and
2
// attach it to a camera asset entity.
3
package main
4
5
import (
6
	"context"
7
	"fmt"
8
	"net/http"
9
	"os"
10
	"time"
11
12
	Lattice "github.com/anduril/lattice-sdk-go/v5"
13
	"github.com/anduril/lattice-sdk-go/v5/client"
14
	"github.com/anduril/lattice-sdk-go/v5/option"
15
	"github.com/google/uuid"
16
)
17
18
const (
19
	// Entity ID to associate the stream with. Replace before running.
20
	entityID = "<ENTITY-ID>"
21
	// RTSP source Lattice will pull from.
22
	rtspURL = "rtsp://<rtsp-host>:<port>/cam"
23
)
24
25
func main() {
26
	latticeEndpoint := os.Getenv("LATTICE_ENDPOINT")
27
	clientSecret := os.Getenv("LATTICE_CLIENT_SECRET")
28
	clientId := os.Getenv("LATTICE_CLIENT_ID")
29
30
	// Remove sandboxesToken from the following statements if you are not developing on Sandboxes.
31
	sandboxesToken := os.Getenv("SANDBOXES_TOKEN")
32
33
	if latticeEndpoint == "" || clientId == "" || clientSecret == "" || sandboxesToken == "" {
34
		fmt.Println("Missing required environment variables")
35
		os.Exit(1)
36
	}
37
38
	headers := http.Header{}
39
	headers.Add("Anduril-Sandbox-Authorization", fmt.Sprintf("Bearer %s", sandboxesToken))
40
41
	LatticeClient := client.NewClient(
42
		option.WithClientCredentials(clientId, clientSecret),
43
		option.WithBaseURL(fmt.Sprintf("https://%s", latticeEndpoint)),
44
		option.WithHTTPHeader(headers),
45
	)
46
47
	ctx := context.Background()
48
49
	// Generate a client-side UUID so the stream is correlatable and the call is retry-safe.
50
	ingressID := uuid.New().String()
51
	fmt.Printf("Starting RTSP ingress stream %s from %s\n", ingressID, rtspURL)
52
53
	// RTSP is a pull protocol: Lattice dials the supplied URL, so no push endpoint
54
	// is returned.
55
	createResp, err := LatticeClient.Video.CreateIngressStream(ctx, &Lattice.CreateIngressStreamRequest{
56
		IngressID: &ingressID,
57
		Title:     Lattice.String("cam-01"),
58
		Rtsp: &Lattice.RtspSettings{
59
			URL: Lattice.String(rtspURL),
60
		},
61
	})
62
	if err != nil {
63
		fmt.Printf("Failed to create ingress stream: %v\n", err)
64
		os.Exit(1)
65
	}
66
	fmt.Printf("Successfully started stream with ID: %s\n", *createResp.GetIngressID())
67
68
	// Attach the new video to the asset entity. A field_path of media.media replaces
69
	// only the media list, leaving every other component on the entity untouched.
70
	_, err = LatticeClient.Entities.OverrideEntity(ctx, &Lattice.EntityOverride{
71
		EntityID:  entityID,
72
		FieldPath: "media.media",
73
		Entity: &Lattice.Entity{
74
			EntityID: Lattice.String(entityID),
75
			Media: &Lattice.Media{
76
				Media: []*Lattice.MediaItem{
77
					{
78
						ItemIdentifier: &ingressID,
79
						Type:           Lattice.MediaItemTypeMediaTypeVideo.Ptr(),
80
					},
81
				},
82
			},
83
		},
84
		Provenance: &Lattice.Provenance{
85
			IntegrationName:  Lattice.String("lattice-video-integration"),
86
			DataType:         Lattice.String("video-association"),
87
			SourceUpdateTime: Lattice.Time(time.Now().UTC()),
88
		},
89
	})
90
	if err != nil {
91
		fmt.Printf("Failed to override entity media: %v\n", err)
92
		os.Exit(1)
93
	}
94
	fmt.Printf("Associated video %s with entity %s\n", ingressID, entityID)
95
}
